Offgridtec® 30w mono 12v solar panel

The solar module 30w mono from Offgridtec (mpn 3-01-001530) works with monocrystalline solar cells with a high efficiency of >18% and is ideal for 12v systems thanks to its 20v operating voltage.

In Offgridtec mono solar modules only cells of the highest quality grade are used and guarantee thanks to modern manufacturing a constant high quality and performance with maximum lifetime.

Features of Offgridtec 30w 12v mono solar panel

• proven quality directly from Offgridtec
• manufactured according to the latest standards
• monocrystalline solar cells
• extremely resistant ESG glass makes the module usable even in the most adverse environmental conditions
• ideal for 12v systems on land or in mobile solar systems
• Frame in anodized aluminum

The mono 30w 12v is one of over 40 proven solar panels from the Offgridtec portfolio and participates in Offgridtecs experience in manufacturing high quality 12v and 24v solar cells. The module can be used in very adverse operating conditions thanks to the extremely resistant solar glass. It can withstand heavy hail and storms or extreme cold and heat without any problems and thanks to the integrated bypass diodes, the module can continue to produce power even in shaded or low light conditions.

The most important technical data at a glance

• Power (Pmax): 30w
• Working voltage (Vmp): 20 V
• Open circuit voltage (Voc): 24 V
• max. current (Imp): 1.5 A
• Short circuit current (Isc): 1.62 A
• max. system voltage: 600 V
• permissible ambient temperature: -40°C - +85°C
• Dimensions: 560 x 360 x 25 mm
• Weight: 2,5 kg

Universally applicable

Offgridtecs 30w 12v Mono is universally applicable for example in 12 volt Solaranlagen on garden houses, allotments or for the power supply of lighting applications, self-sufficient systems of signal and surveillance technology and many more. But also in mobile systems such as in mobile home solar systems this panel makes a good figure.

Scope of delivery:

Offgridtec 3-01-001530 30w mono 12v solar panel
