Luxen Solar 450W Bifacial Solar Module TopCon Luxneri Series N5 Full Black

The Luxneri N5 series bifaccial 450W Full Black solar module from Luxen Solar (MPN LNDX-450ND) sets new standards in solar technology. It combines innovative technologies such as LECO N-TOPCon cell technology and a 96-cell half-cut layout to maximize efficiency. It also uses SMBB half-cut cell technology, which helps optimize performance.

The monocrystalline module also impresses with excellent anti-PID and low LID performance values as well as high hotspot resistance. Its stylish full-black design makes it ideal for installation in solar systems on residential buildings, balcony power plants, and many other applications.

about the 450W Luxen N5 solar module

• LECO N-TOPCon cell technology
• SMBB half-cut cell technology
• Low BOS & LCOE
• Bifacial cell module technology
• Excellent anti-PID and low LID performance
• Reduced hotspot risk
• 3 bypass diodes - minimized power loss in case of shading
• high cell efficiency of over 22.52%

LECO N-TOPCon cell technology

Advanced TOPCon (Tunnel Oxide Passivated Contact) technology is a further development of PERC technology and aims to increase the efficiency of solar cells. This technology is complemented by Low Efficiency Cell Optimization (LECO), which aims to further optimize the overall performance of the cells, especially under less than ideal lighting conditions. During the manufacture of the solar modules, an ultra-thin oxide layer is applied, followed by a conductive layer, resulting in what is known as a passivated contact. This design not only improves the performance of the solar cells in low light conditions, but also contributes to higher annual energy production.

In addition, the combination of TOPCon and bifacial technology enables even greater power efficiency, as the cells are able to absorb 15% more reflected light. These synergistic effects lead to a significant increase in energy yield and make the solar cells an outstanding choice for modern photovoltaic applications.

Half-cell technology

In half-cell technology (also known as "half-cut"), conventional silicon cells are divided into two halves using a laser. These halved cells are then connected in parallel at the center, which reduces resistance losses and thus increases the performance of the solar module.

Bifacial cells

Bifacial modules offer a decisive advantage thanks to their transparent backs and special cell technology—they also utilize reflected light. This leads to a significantly increased energy yield and makes these modules a particularly efficient choice for your solar system.

Low BOS & LCOE

The term "BOS" (Balance of System) covers the total costs for installing a solar system, including mounting systems, cabling, and inverters. A low BOS value indicates a cost-efficient installation that improves the economic efficiency of the system.

The "LCOE" (Levelized Cost of Energy) determines the average cost per kilowatt hour over the lifetime of the energy project. A low LCOE value means that the energy generated is cost-effective, which increases its competitiveness compared to other energy sources.

Technical data

• maximum power: 450W
• Module voltage (Vmp): 30.08V
• max. current (Imp): 14.96A
• Open circuit voltage (Voc): 35.21V
• Short-circuit current (Isc): 16.02A
• Module efficiency: 22.52%
• max. operating voltage: 1500V DC
• Operating temperature range: -40°C to +85°C
• Dimensions: 1762 x 1134 x 30 mm
• Cells: 96 (6x16)
• Protection class IP68
• Connection: MC4
• Weight: 24 kg

Scope of delivery

1x Luxen Solar 450W Luxneri N5 Mono Bifacial Full Black Solar Module
