Offgridtec® 10w mono 12v solar panel
Product is expected to be back in stock on 4 April 2025
The solar module 10w mono from Offgridtec (mpn 3-01-001265) works with monocrystalline solar cells with a high efficiency of >22% and is ideal for 12v systems thanks to its 20v operating voltage.
In Offgridtec mono solar modules only cells of the highest quality grade are installed and guarantee a constant high quality and performance with maximum service life thanks to state-of-the-art manufacturing.
Features of Offgridtec 10w 12v mono solar panel
- Power (Pmax): 10w
- proven quality directly from Offgridtec
- high operating voltage of 20v, perfect for 12v systems
- manufactured according to the latest standards
- monocrystalline A-grade solar cells
- extremely resistant ESG glass makes the module usable even in the most adverse environmental conditions
- 1 blocking diode - prevents current backflow when directly charging 12v batteries
- 1 bypass diode - minimizes power loss during shading
- ideal for 12v systems on land or in mobile solar systems
Proven, immediately operational solar module
The mono 10w 20v is one of over 40 proven solar panels from the Offgridtec portfolio and participates in Offgridtecs experience in manufacturing high quality 12v and 24v solar cells. The module can be used in very adverse operating conditions thanks to the extremely resistant solar glass. It can withstand heavy hail and storms or extreme cold and heat without any problems and thanks to the monocrystalline A-grade cells you can count on noteworthy yields even on cloudy days.
The most important technical data at a glance
- Working voltage (Vmp): 20 V
- Open circuit voltage (Voc): 24 V
- max. current (Imp): 0.5 A
- Short circuit current (Isc): 0.54 A
- max. system voltage: 600 V
- permissible ambient temperature: -40°C - +85°C
- Dimensions: 230 x 370 x 25 mm
- Weight: 1,0 kg
- Part number: 3-01-001265
Universally applicable
Offgridtecs 10w 20v Mono is universally applicable for example in 12 volt Solaranlagen on garden sheds, allotments or for the power supply of lighting applications, self-sufficient systems of signal and surveillance technology and many more. But also in mobile systems such as in mobile home solar systems this panel makes a good figure.
Scope of delivery:
Offgridtec 3-01-001265 10w mono 12v solar module
