The Steca PR 1010 is suitable for photovoltaic (PV) systems, for charging 12 V or 24 V batteries, for hobby and leisure use, for residential, commercial, and industrial applications, and for small businesses.
Unlike the PRS series from Steca, the PR series has a display that makes the controller easy to operate. In addition, all current operating parameters can be read on the display.
The controller is generally only suitable for the following rechargeable 12 V or 24 V
battery types and consumers:
- Lead-acid batteries with liquid electrolyte
- Sealed lead-acid batteries; AGM, GEL
- 12V and 24V consumers that can be connected directly to the regulator (right-hand connection pair)
electronic functions
- Protection against reverse polarity of connected solar modules
- Protection against reverse polarity connected consumers at the load output
- Protection against reverse polarity connected batteries
- Battery charging and discharging are prevented
- Short-circuit protection at the module input
- Short-circuit protection at the load output
- Protection against excessive charging current
- No-load test during operation without battery or load
- Reverse current protection
- overvoltage and undervoltage protection
- over-temperature protection
- Deep discharge protection / overcharge protection
- Complies with European CE standards
Displays
- Graphic LCD display for operating parameters, error messages, self-test
Operation
- Simple menu-guided operation
- Programming via buttons
- Manual load switch
Options
- Prepayment interface
- External temperature sensor
- Alarm contact
Certificates
- World Bank certificate for Nepal
- CE compliant
- RoHS compliant
- Made in Germany
- Developed in Germany
- Manufactured under ISO 9001 and ISO 14001
Manufactuerer Information
Steca
Steca Elektronik GmbH
Mammostraße 1
87700 Memmingen
Germany
Mail: info@steca.com
Tel.: +49 833185580
