The T-BAT high-voltage battery system from Solax (MPN: 024827) is a flexible energy storage solution that adapts perfectly to your individual needs. With a usable capacity ranging from 5.8 kWh to 23 kWh, this modular storage system offers a flexible and efficient solution for residential and commercial solar power systems. Thanks to the LiFePO₄ cells, IP65 protection rating, and comprehensive safety features, operation is safe at all times. Flexible mounting options—both on the wall and on the floor—allow for easy installation in any home. With CAN and RS485 communication, the T-BAT-SYS-HV-5.8 is compatible with Solax inverters and supports intelligent monitoring and control of energy flow.
The SolaX Triple Power Battery Set includes:
T-BAT Master Battery
The SolaX T-BAT-SYS-HV-5.8 (MPN: 1020030064) is a state-of-the-art high-voltage home storage system designed specifically for photovoltaic systems. With a usable capacity of 5.1 kWh and a depth of discharge of 90%, it ensures efficient and long-lasting storage of solar energy. Equipped with high-quality LiFePO₄ cells and an IP65 protection rating, it offers maximum safety and reliability during operation. Flexible wall or floor mounting allows for easy integration into various living situations. Thanks to CAN and RS485 communication, the battery is compatible with Solax inverters and supports intelligent monitoring and control of energy flow, thereby optimizing self-consumption of solar power.
- Usable capacity of 5.1 kWh at 90% depth of discharge for maximum energy yield
- Over 6,000 charge cycles for a long service life and sustainable operation
- Intelligent monitoring and control of energy flow to optimize self-consumption
Technical Specifications
- Nominal voltage: 115.2 V
- Operating voltage: 100–131 V
- Total capacity: 5.8 kWh
- Usable capacity: 5.1 kWh
- Cycle life: >6,000 cycles
- Operating temperature: Charging 0–55 °C / Discharging –10–55 °C
- Storage temperature: –20–30 °C (12 months), 30–55 °C (6 months)
- Warranty: 10 years
- Weight: 72.2 kg
- Dimensions (L x W x H): 474 x 193 x 708 mm
T-BAT Slave Battery
The Solax HV11550 5.8 kWh battery (MPN: 1020030063) is a high-performance expansion for the Solax Triple Power storage system and serves as a slave battery in combination with the T-BAT H 5.8 master battery. The usable capacity of 5.2 kWh enables a reliable energy supply for residential and commercial applications. Thanks to its modular design, the storage system can be flexibly and easily expanded up to 23.2 kWh and adapted to growing energy needs.
- Highly safe LiFePO₄ technology for long-lasting and stable performance
- Rated capacity of 5.8 kWh with a 90% depth of discharge for maximum utilization
- Plug & Play installation for easy expansion
Technical Specifications
- Rated capacity: 5.8 kWh
- Usable capacity: 5.1 kWh
- Nominal voltage: 115.1 V
- Operating voltage: 100–131 V
- Cycle life: > 6,000 cycles
- Operating temperature (charging): 0°C to +55°C
- Operating temperature (discharge): -10°C to +55°C
- Storage temperature: -20°C to +30°C
- Protection class: IP65
- Weight: 72.2 kg
- Dimensions: 474 x 193 x 708 mm
