Phaesun Hybrid Charge Controller All Round 1000_24V
Shipped in 2-5 days
Similar Products
Shipped in 10-14 Werktage
Shipped in 10-14 Werktage
Product is expected to be back in stock on 27 December 2024
Product is expected to be back in stock on 27 December 2024
Addon Products
Shipped in 1-3 days
Shipped in 1-3 days
Shipped in 1-3 days
Shipped in 1-3 days
Shipped in 1-3 days
Shipped in 1-3 days
Shipped in 1-3 days
Shipped in 1-3 days
Shipped in 1-3 days
Shipped in 1-3 days
Thanks to a many control functions the All Round series is very well-suited for wind/solar applications, street lighting or surveillance systems. Technical data:
- designed for 24V-systems
- max. 21A wind energy (1000W)
- max. 6A solar energy (300W)
- 2 x DC output: max. 10A total, 3 different modes
Reliability: Intellegent, module based design, simple mechanics, various functions. Thanks to high-quality components and a strict production process the regulator is able to last very long even under bad circumstances. Steplessly PWM regulated
Voltage and current limitating charging mode: when the battery's max. voltage is reached the controller switches to voltage limitating mode. If the voltage, produced by the wind turbine, exceeds the max. voltage the regulator slows down the turbine. Each DC output with various control modes
LCD Display:
The LCD display shows status information and system parameter in numbers and graphical form: battery voltage; wind generator voltage and output; solar module voltage and performance, charging current, output control modes,
time control, light controll option, day/night detection, charging level, under/overvoltage of the battery, etc.
