The high-end Phaesun Hybrid Charge Controller All Round 400_12 was especially developed for 12VDC offgrid wind/solar hybrid systems.

Thanks to many control possibilities the All Round series is very well suited to wind/solar systems, street lighting and surveillance systems.

Technical data:

for 12VDC-systems
wind energy: max. 33A (400W)
solar energy: max. 12A (150W)
2 x DC outputs: max. 10A, 3 different modes

Features:
Reliability: Intellegent, module based design, simple mechanics, various functions. Thanks to high-quality components and a strict production process the regulator is able to last very long even under bad circumstances.

Steplessly PWM regulated
Voltage and current limitating charging mode: when the battery's max. voltage is reached the controller switches to voltage limitating mode. If the voltage, produced by the wind turbine, exceeds the max. voltage the regulator slows down the turbine.

Each DC output with various control modes

LCD Display:
The LCD display shows status information and system parameter in numbers and graphical form: battery voltage; wind generator voltage and output; solar module voltage and performance, charging current, output control modes,
time control, light controll option, day/night detection, charging level, under/overvoltage of the battery, etc.

Zertifikat_All-Round-400_12.JPG Download

Bedienungsanleitung_All-Round-400_12_EN.pdf Download
