MC4 Connector Pair - plug and socket 4-6mm²
Product number:
2H-FURD-397Z
2H-FURD-397Z
4.75177
141
Shipped in 1-3 days
Product number:
2H-FURD-397Z
Addon Products
8-01-004910
MC4 Wrench (assembly tool for MC4-connectors)
With this wrench strain reliefs and cable connections on MC4-plugs can be screwed shut and unscrewed with the appropriate torque.
Features:
set co...
Shipped in 1-3 days
Shipped in 1-3 days
8-01-006300
Lapp solar cable SOLAR XLR-R 1X4 WH/BK
Lapp solar xlr-r cables are weather-, abrasion- and uv-resistant photovoltaic cables. These halogen-free, double-insulated and cross-linked solar cabl...
Shipped in 1-3 days
Shipped in 1-3 days
8-01-006295
Solar Cable H1Z2Z2-K 1X6 WH/BK
Lapp SOLAR H1Z2Z2-K cables are weather, abrasion and UV-resistant photovoltaic cables. These halogen-free, double-insulated and cross-linked solar cab...
Shipped in 1-3 days
Shipped in 1-3 days
This set includes a male and a female MC4-plug. These plugs are original Stäubli MC4-plugs.
Details:
- touchproof, unplugged IP2X
- protection, plugged IP67
- temperature range from -40° to 90°C
- isolation material: PA
- snap-in locking-system
- cable strain relief according to IEC 61984 (06.2001)
- contact system: MC-contact lamellas
- contact material: tinned copper
- flame class:UL94-V0
- protection class: II
- system voltage up to 1000V
- rated amperage up to 30A
Manufacturer:
Stäubli
Plug:
MC4 PV-KBT4/6I
2H-FURD-397Z
