Kemo M100N Car Ultrasonic Marten Repeller

The Kemo M100N ultrasonic marten repellent for cars generates aggressive ultrasonic tones that are inaudible to humans but extremely annoying to martens, which therefore avoid them if possible. Installation in the engine compartment of the car. Ultrasonic marten repeller for use in vehicles, houses, and attics. Generates extremely loud, pulsating ultrasonic tones with a special dome speaker.

Technical data

• Powerful hemispherical dome speaker, 2-fold effective—ultrasound + pulsating light
• Operating voltage: 11-15 V/DC (car battery)
• Soft start to prevent interference with the on-board computer
• Average power consumption: <2mA
• Ultrasonic frequency: approx. 23 kHz
• Beam angle: approx. 140°
• Sound pressure: max. approx. 110 dB ±20%
• Sound: loud pulsating
• Speaker: Ceramic piezo ultrasonic speaker with aluminum dome diaphragm
• Visual deterrent: pulsating LED
• Temperature range: approx. -25°C to +80°C
• Electronics: waterproof encapsulated
• Fuse in fuse holder: F500mA
• Protected against voltage spikes in the vehicle electrical system up to 40V (<20 ms)
• Suitable for vehicles with CAN data bus

Installation instructions:

If the device is to be used against martens, it should be installed in the engine compartment. Care should be taken to ensure that there is as much free space as possible in front of the speaker opening of the device so that the ultrasonic sounds can spread as widely as possible in the engine compartment. Installation and commissioning may only be carried out by competent persons who also assume liability for any damage. Ultrasonic waves propagate in a straight line like light, which means that the tones may not be effective in all corners. If the engine compartment is very cluttered, it may be necessary to install several devices. You should try to align the speaker opening so that the cables and hoses most at risk of marten damage are directly exposed to the marten repellent. The device must be installed in such a way that no water or dirt can penetrate the housing. After applying the operating voltage of 11-15 V/DC, the built-in LED on the device will flash. If this indicator light does not flash slowly, either there is no voltage or you have connected the voltage incorrectly. Please note that ultrasonic sounds are very stressful for animals.

Scope of delivery:

1x Kemo M100N car ultrasonic marten repellent
