The heavy-duty trapezoidal clamp from Offgridtec (MPN 021535) is an essential fastening element for installing the aluminum mounting rails of a photovoltaic system. It ensures secure fastening that provides a reliable hold even in demanding weather conditions. With its innovative design, the clamp ensures optimum load distribution and minimizes the risk of twisting or damage to the mounting structure. The trapezoidal clamp is suitable for flat, metal and pitched roofs, as well as roofs with special coatings, and offers a versatile solution for various installation requirements in photovoltaics.
The EPDM rubber pads included in the scope of delivery are specially manufactured so that one side is self-adhesive to ensure easy mounting on the metal bracket.
Features of the heavy-duty trapezoidal clamp
- made of stainless steel
- weather-resistant
- optimum load distribution
- for maximum stability and durability
- Simple assembly incl. accessories
Technical data
- Material: Stainless steel
- Grade: A2 / 1.4301
- Thickness: 3 mm
- Dimensions: 100 x 88 x 27 mm
- Weight: 0,25kg
Scope of delivery:
1 x metal roof bracket
4 x stainless steel screws M6x25 mm with waterproof pad
1 x stainless steel screw M8x25 mm
1 x M8 nut
1 x washer
1 x spring washer
4 x EPDM rubber pad (with one side self-adhesive)
