Goal Zero External 30a mppt-x for Yeti Power Station
Shipped in 1-3 days
Goal Zero's external 30A mppt kit (mpn 98085) ensures that generated energy can be quickly and safely stored in the Goal Zero Yeti expansion battery. The kit includes a Victron SmartSolar mppt 100/30 charge controller, a Goal Zero HPP extension cable to connect Goal Zero solar panels, and a Goal Zero EC8 extension cable so you can connect the Yeti Tank.
Victron SmartSolar mppt 100/30
The Victron mppt 100/30 charge controller is equipped with the mppt (maximum power point tracker) system. Especially in overcast conditions, when light intensity is constantly changing, the super-fast mppt algorithm improves energy output. The mppt technology ensures that the charge controller automatically adjusts to the changing voltage, transferring energy from the solar panel to the battery in a very effective way. By using a charge controller with mppt system, you use your solar panels up to 30% more effectively.
In addition, the Victron SmartSolar mppt 100/30 has an integrated Bluetooth module. A Bluetooth-enabled smartphone can display a variety of data live. The wireless solution to set up, monitor and update the controller using Apple and Android smartphones, tablets or other devices.
Technical data Victron mppt 100/30
- System voltage: 12V/24V
- max. charging current: 30A
- max. PV open circuit voltage: 100V
- max. PV power 12v: 440W
- max. PV power 24v: 880W
- integrated protection against battery polarity reversal
- high maximum efficiency of 98
- multi-stage and adaptive charging algorithm
- Day/night time control and light dimming option
- Protection class ip: ip43 (electronic components), ip22 (connection area)
Scope of delivery:
1x Victron SmartSolar mppt 100/30 charge controller
1x Goal Zero HPP extension cable
1x Goal Zero EC8 extension cable
